Single Port Temperature and Humidity Sensor
In situations where both temperature and humidity can be critical you can keep up to speed on the current conditions using this sensor. Combining temperature and humidity into the one sensor frees up an additional intelligent sensor port on your base unit.
- Temperature and Humidity Monitoring on a single sensor port
- Own SNMP OID for data collection via a network
- Temperature measurement from -55ºC – +75ºC
- Relative Humidity measurement from 0% – 100%
- Powered by base unit, no additional power needed
Setup is simple with the sensorProbe+ and securityProbe autosense function. Once plugged into the intelligent sensor port the base unit automatically detects the presence of the sensor and configures it for you.
Temperature and humidity for data center monitoring, remote sites and industrial controls.
All you need to do is set your thresholds for low and high warning and critical parameters. The built in graphing function of the base unit gives you a pattern of temperature or humidity trends over time.
Sensor is available in 2 variations:
Fixed length temperature and humidity sensor with 1ft of cable attached
Variable length temperature and humidity sensor. Ships with free 5ft CAT5 cable, user can extend up to 330ft.
Our Single Port Temperature/Humidity Sensor is calibrated using dedicated equipment which is calibrated according to ISO/IEC 17025 and calibrated by comparison against natural standards, natural physical constants, consensus standards, or by ratio type measurements using self-calibrating techniques.
Standards incorporated to establish this comparison are NIST and NPL traceable.
| Temperature | |
| Measurement Range | -55°C to +75°C -67°F to +167°F |
| Measurement Resolution | sensorProbe+ series 0.1°C increments 0.2°F increments securityProbe series 0.5ºC increments 0.9ºF increments sensorProbe series 1ºC increments 1ºF increments |
| Measurement Accuracy | sensorProbe+ series and securityProbe series ±0.5°C accuracy from -10°C to +75°C ±0.9°F accuracy from +14°F to +167°F sensorProbe series ±1°C accuracy from -10°C to +75°C ±1°F accuracy from +14°F to +167°F |
| Humidity | |
| Measurement range | 0 to 100% Relative humidity |
| Resolution | 1%RH increments, 0.01%RH sensor reading |
| Accuracy at | At 25°C Min : ±2%RH Max : ±5% RH |
| Interface | |
| Communications cable | RJ-45 jack to sensor using UTP CAT5e/6 cable |
| Power source | Powered by the base units. No additional power needed |
| Power Consumption | Typical 17.25mWatt, 1.45mA |
| Maximum Cable Length | Run length
THS00 – 330ft (100 meters) with high quality, low capacitance CAT5/6 cable THS01 – 100ft (30 meters) with high quality, low capacitance CAT5/6 cable |
| Sensor type | Semiconductor, microprocessor controlled |
| Dimensions | 56 x 55 x 33.3 mm |
| Mounting | DIN rail mounting Screw mounting |
| Sensor count | 2 |
| Sensor count (NIST2/NIST3) | 3 |
| Important Note | The fixed one foot type or THS01 are not designed to be extended. If you need to extend these sensors then you need to use the THS00 (remote type). We also do not recommend you trying to connect any of our AKCP sensors including the temperature and dual temp humidity sensors though patch panels or using the RJ-45 couplers to extend them. Please see the temperature sensors product manual or FAQ in our knowledge base for more details regarding this. |
| Compatibility | THSxx-NIST2 and THSxx-NIST3 compatible with sensorProbe+ series only |
