Monitor up to 4 intelligent sensors from a single IP address
The world’s best selling environmental monitoring platform has been upgraded. Start with a basic package to enable monitoring over a single cabinet. Expand to a full data center monitoring solution, one cabinet at a time. Every computer rack monitored using AKCPro Server. The sensorProbe2+ Expansion, equipped with a Modbus interface, acts as a gateway from Modbus to SNMP
- IP based, including SNMPv3, HTTPS, VPN and MQTT
- Send encrypted SNMP Trap and Email Notifications
- Supports 4 Intelligent Sensors or up to 20 Dry Contacts.
- 2x sensor ports enabled by default. Unlock all 4 ports with Pro software upgrade
- Optional cellular modem with external antenna
- Optional Expansion Module connectivity
- Up to 80 Virtual Sensors
- Optional Modbus (SP2+E)
- Optional Power over Ethernet (PoE)
Remote Sensor Monitoring
SP2+ is compatible with all AKCP sensors, making it an extremely versatile and cost-effective remote monitoring solution. Suitable for small data center temperature monitoring, refrigerator temperature monitoring.
Environmental Monitoring Sensors
Environmental Monitoring is important to daily operations and health of equipment. Deploy temperature sensors for data center monitoring and server rooms. Monitor water leaks and much more.
Security Sensors
RFID cabinet locks, door contacts and motion detectors will keep you in tune with the security situation at your sites down to cabinet level. Control who can access cabinets and when, centrally managed and monitored through AKCP Pro Server.
Power Sensors
AC Voltage sensor, DC voltmeters, sensor-controlled relays and power metering can all be done on the SP2+
Specialized Sensors
Tank Level Sensors can monitor for liquid levels in fuel tanks, oil storage, chemical tanks and so on. Any tank up to 2 meters in depth can be monitored. Alarms generated when levels drop to critical levels, making sure you can re-fill with sufficient notice. Other specialized sensors include the key switch override, to disable notifications while maintenance work is being performed, and a programmable LCD sensor display.
| Sensor Ports | 4 RJ-45 Sensor Ports for connecting AKCP Autosense Sensors Up to 20 Dry Contact Input and Output (0VDC/5VDC) NOTE: SP2+ Basic ships with 2 sensor ports unlocked, the Pro version unlocks all 4 ports |
| Mounting | 0U rack-mountable Compatible with AKCP’s DIN Rail Clips |
| Status Indication | LED indication for power LED for network connectivity LED for sensor online and threshold status Internal Buzzer alarm |
| Components | Manufactured using highly integrated, low power, surface mount technology to ensure long term reliability. |
| MTBF | 1,400,000 Hours based experience with sensorProbe units |
| Connectivity | Optional Internal Cellular Modem (EU / US frequencies available). Includes External Antenna |
| Optional Expansion Capabilities | Expansion port uses 1 sensor port Connect up to 4 Cabinet Control Units with SP2+E |
| Dimensions | Size : 4.5″ x 2.5″ x 1.25″ Weight : 0.3 Kg |
| Power Requirements | Voltage : 5 VDC, 3Amp (Including Optional Modem) Optional PoE IEEE 802.3af |
| Supported Protocols | SNMPv1, SNMPv2c, SNMPv3 Modbus TCP, Modbus RS485 MQTT, MQTTS Rsyslog RADIUS TACACS HTTP, HTTPS IPV6 NTP VPN Encrypted E-mail (SSL/TLS, STARTTLS) |
| Licensing | Pro licensing: SP2+PRO-L: Unlock the following features: Maps, 3rd Party Modbus, IPv6, SNMPv3, VPN, Access Control User, Heartbeats, Modbus, Remote UI Access Virtual Sensor pack: VS Virtual sensor (pack of 5 sensors). Maximum of 80 virtual sensors. * ** Every SP1+ comes with 5 free virtual sensors 5 Dry Contact: DC5: Radius: RAD TACACS+: TAC |
| Operating Environment | Temperature : Min. 0°C – Max. 70° C (Industrial Option available for Min. -25°C – Max. 70°C Humidity: Min. 20% – Max. 80% (Non-Condensing) |
