Product Matrix

	sensorProbe	sensorProbe+	securityProbe	securityProbe+
Mounting	0U Rackmount Wall Hang	0U Rackmount Wall Hang	1U Rackmount	1U Rackmount
Mounting	1U Rackmount	1U Rackmount
Interface ports	100 Base-T Ethernet RJ-45	100 Base-T Ethernet RJ-45	100 Base-T Ethernet RJ-45	100 Base-T Ethernet RJ-45
		1 optional RJ-45 Expansion Port and 1 BEB Port	2 or 4 Expansion Ports	1 RJ-45 Expansion and 1 BEB Port
			1 RS485 Modbus port	WiFi adapter
Power Consumption	Typical 1-1.5 Watt	Typical 1 Watt	Typical 5 Watt	Typical 2 Watt
Input	2, 4 or 8 Intelligent Sensor Ports for connecting AKCP sensors (RJ45)	4 or 8 Intelligent Sensor Ports for connecting AKCP sensors (RJ45)	8 Intelligent Sensor ports for connecting AKCP Sensors (RJ-45)	4 or 8 Intelligent Sensor Ports for connecting AKCP sensors (RJ45)
	20 or 60 optional dry contact ports	10 or 20 dry contact ports	20 or 60 dry contact ports	10 or 20 dry contact ports
			1 USB port	4 USB ports
			Audio In (Analog) 2.5″ jack 4 analog or digital camera ports (optional)
Output	Configurable output signals (0VDC/5VDC) on any of the Intelligent Sensor ports	Configurable output signals (0VDC/5VDC) on any of the Intelligent Sensor ports	Ext. Speaker Out, 2.5″ (Analog)	Configurable output signals (0VDC/5VDC) on any of the Intelligent Sensor ports
Output			Mic Out (Analog) 2.5″ for modem application
Operating Environment	Temperature : Min. -35°C – Max. 80°C	Temperature : Min. -35°C – Max. 80°C	Temperature : Min. -35° C – Max. 55° C	Temperature : Min. -35° C – Max. 55° C
Operating Environment	Humidity : Min. 20% – Max. 80% (Non-Condensing)	Humidity : Min. 20% – Max. 80% (Non-Condensing)	Humidity : Min. 20% – Max. 80% (Non-Condensing)	Humidity : Min. 20% – Max. 80% (Non-Condensing)
Components		CPU: AKCP STM32F4 MCU	CPU: AKCP i.MX25 Processor	Powered by Raspberry Pi
Components		16 MB Flash memory	On-board SD Card Slot

Feature	sensorProbe	sensorProbe+	securityProbe	securityProbe+
SNMP v1/2c
SNMPV3	–
HTTPS	–
IPv6	–	–
Thermal Map Sensor	–		–
AKCP Swing Handle Lock compatible	–		–
LCD Sensor	–		–
ILPM Sensor	–		–
Sensor Status Light	–		–
Linux OS	–	–
Up to 150 sensors supported	–
Up to 500 sensors supported	–	–		–
Up to 50 CCU supported	–	–		–
Mapping feature	–	–
Sensor Graphing
E-mail Notification
Secured E-mail Notification	–
SMS Notification with optional modem	–
Call Notification with optional modem	–
Dry Contact Notification
Siren Notification	–
SNMP Trap Notification
SNMP Set Notification	–
SNMP Trap Receiver	–
Modbus TCP	–
Modbus RTU	–
Modbus Write	–
Boolean Function	–
RADIUS	–	–		–
SSH Terminal	–	–
Nagios utility built-in	–	–		–
FTP Upload	–	–
Relay Action	–
Windows Notification	–	–
Wake Up/Shutdown Notification	–	–
Picture Log Notification	–	–		–
Sound Log Notification	–	–		–
Text to Speech Notification	–	–
Heart Beat notifications
Alarm Sound	–
5 dry contact input			–
Expansion Ports	–
CCU Compatible	–
E-Sensor8 Compatible	–
E-Opto16 Compatible	–
3G/4G Internal Modem Option	–
Analogue Cameras	–	–		–
Digital Cameras	–	–
PTZ Control	–	–
Expandable Storage	–	–
Scripting Language Support	–	–
Full Virtual Sensor Suite	–	–
Reduced Virtual Sensors Suite	–
VPN with AKCPro Server	–	*
VPN with 3rd Party Server	–	–		–
UFLS Sensor compatible	–
8PRB Sensor compatible	–
DCT Sensors compatible	–
Thermocouple Sensors compatible	–
ProbeSwitch Sensor compatible	–	–		–
PMS Sensor compatible	–
IODC8 Compatible	–

Licensed feature Not supported yet Supported * on sensorProbe+ enabling the VPN feature reduces the total number of sensors supported to 50

	sensorProbe	sensorProbe+	securityProbe	securityProbe+
Dry Contacts	5, 10, 20 or 60	5, 10, 15*, 20 or 60	20 or 60	5, 10, 15*, 20 or 60
Intelligent Sensors	2, 4 or 8	4 or 8	8	4 or 8
Cameras	–	–	Max 4	Max 2 (USB)
Connect Voice modem	–
Connect GSM / GPRS Modem	–
External Microphone	–	–		–
External Speaker	–	–		–
Expansion Modules	–
POE Option		–	–	–

* with 5-dry contact cable and software license

	sensorProbe	sensorProbe+	securityProbe	securityProbe+
Send e-mail alerts
SNMP Traps
Send SMS	*	**	**	**
E-mail/SMS alert if phone line fails	–	**	**	**
Control Relay
FTP upload	–	–
Picture Log	–	–		–
Skype call alerts	–	–		–
Telephone call alerts	–	**	**	**
Custom Scripts	–	–
Fax	–	–
Sound log	–	–		–
Control Siren and strobe
Mobile Access	–	–		–
Wake Up / Shutdown	–	–
Alarm sound	–
Windows alerts	–	–

* Requires third party E-mail to SMS gateway ** Requires GSM modem (not included)

	sensorProbe	sensorProbe+	securityProbe	securityProbe+
Temperature Sensor
Water resistant Temperature Sensor
daisyTemp Sensor	–
Dual Temperature/Humidity Sensor
Water resistant Temperature/Humidity Sensor
Water Sensor
Security Sensor
Airflow Sensor
Dry contact
AC Voltage Detector
Digital Voltmeter
Power Monitor Sensor	–
4-20 mA Converter
Sensor Controlled Relay
AC Sensor Controlled Relay
DC Sensor controlled relay
8 Port Sensor Relay	–
Smoke Detector
Motion Detector
Siren & Strobe
Universal Mount Camera	–	–
5 Dry Contact Inputs cable	*		–
Thermocouple Sensor	–
ropeWater Sensor
IO-Digital8 Sensor	–
Fuel Level Sensor	–
J & K Thermocouple Adapter	–
Pan and Tilt Dome Camera	–	–		–
Temperature Sensor as Thermostat
Sound Detection	–	–		–
Third Party Analog Cameras	–	–		–
Third Party Analog PTZ Cameras	–	–		–
VibrationDetect Sensor
Thermal Map Sensor	–		–
Swing Handle Lock	–		–
LCD Sensor	–		–
ILPM Sensor	–		–
Sensor Status Light	–		–

* sensorProbe2 only

	sensorProbe	sensorProbe+	securityProbe	securityProbe+
Sensor Mapping Module	–	–
Sensor Notification Wizard	–
Keep alive e-mail
Keep alive trap
Network Time Protocol (NTP)
Password Protection
Advanced log filter	–
Sensor Graphing
Picture Logging	–	–		–
Sensor Autosense
Guest Access	–
PTZ Controller	–	–		–
Modbus	–
Boolean	–
RADIUS	–	–		–
Nagios	–	–		–
SSH Terminal	–	–
SNMP Trap Receiver	–
Time Tracking	–	–
Multilingual Web Interface	–
1U DIN rail rackmount kit	*	*	–	–
Split 1U DIN rail rackmount kit
Double rack mount kit	**	–		–
